Original price was: $8,749.99.$5,249.00Current price is: $5,249.00.
The newest generation of security camera systems is here. With Commercial 5MP resolution,this surveillance system from GW Security will bring a brand new level of detail to your security monitoring. This system includes our GW4232N2 4K Network Video Recorder. Whether you are looking to monitor your business or protect your home, this powerful security camera system will help you secure the things that matter most.
GW4232N2-GW5076MIP Specifications
4K DVR can support up to 32 cameras
32 × 5MP Bullet IP Cameras
Maximum Night Vision Range
Expandable up to 20TB
GWView App
Resolution
Vandal Proof
Night-vision
Motorized Zoom
IP66 Rating
Mobile Viewing
PoE Power
5MP video has 100% more pixels in a frame than standard 1080P (2MP) HD. Additional pixels make the digital zoom more effective, providing more details at close distances or the ability to digitally zoom in on details at a greater distance than before.
Human detection is the latest tech in reducing fake alarms for customers. Human detection and tracking are tasks of computer vision systems for locating and following people in video imagery. They are generally considered the first two processes in a video surveillance pipeline and can feed into higher-level reasoning modules such as action recognition and dynamic scene analysis.
Built-in microphone cameras are perfect for recording even the quietest audible disturbance. Place the camera on a terrace, patio, porch, or any indoor room in your home for perfect audio recordings with only crisp, clear quality.
With Power over Ethernet (PoE), you only need to connect your Ethernet cable to power your PoE security cameras. Data also travels both ways through an Ethernet cable, PoE software not only sends data and commands to devices, but it also collects data. This gives you flexibility to install your security cameras almost anywhere you want, without the extra worries of keeping them plugged in nearby electrical outlets.
Optical Zoom is the best quality of zoom, using the lens in the camera to magnify the scene to provide the best and clearest image. Optical Zoom is like using a pair of binoculars to see farther away. With 4X Optical Zoom, you are given more choices for camera placement and zoom into what is most important. The lens inside the camera has the ability to move producing much better-quality images.
Digital zoom is available when used with our security DVR recorders and is useful for HD security cameras with resolutions of 1080P and higher. Since higher resolution cameras and the better the quality of the digital zoom produce the most detailed images, 4K resolution security footage provides the best quality.
While digital zoom can be done after video has been recorded, optical zoom needs to be executed or set in live video at the actual moment the incident of interest happens.
Motorized zoom lenses allow control of the optical zoom lens at the touch of a button from the recorder, PC software, and mobile app. You can control the zoom and focus of the camera when you are watching the camera in live view and adjust the camera’s field of view according to your preferences.
2.8~12mm Optical Zoom Motorized Lens offers a lot more range than cameras with fixed lenses and allows you to adjust the angle of view from 125 degrees to 37 degrees – a smaller lens value will show a shorter viewing distance and a wider angle field of view. A larger lens value will allow for a longer viewing distance but a narrower field of view.
GW’s high-quality LEDs allow these HD IP cameras to see up to 100ft in complete darkness for 24-hour-a-day protection. GW Cameras use the latest high intensity IR LED technologies for maximum coverage. The image shown is an actual capture from a 5MP camera in total darkness.
IR range and image quality can be affected by surfaces that absorb or reflect the IR light differently when in total darkness. Camera location or position may need to be adjusted to optimize the images. Some ambient lighting provides the best results for night surveillance.
An IP66-rated security camera has a rugged design and durable construction that’s rated for general outdoor use. An IP66-rated camera offers excellent performance even in harsh conditions such as: Dust storms, Wind, rain, sleet, even blowing snow. What performance specs can you count on from an IP66 standardized rating? You can count on an IP66 to provide the following:
Level 6 Dust Protection: The highest level of dust protection, with no intrusion of dust whatsoever permitted.
Level 6 Water Protection: The third-highest level of water protection, impervious to precipitation or hose-directed water streams, blowing snow and sleet.
IK10 is the highest rating possible for protection against impact in Security Cameras. Feel assured this camera can be used in applications with high rates of vandalism. IK10 rated will generally withstand a variety of elements better than standard Dome or Bullet Style Cameras.
up to 4K/8MP/5MP/3MP 1536p @ 30fps Realtime each channel
NVR built-in 2 USB ports, 2 SATA HDD port(up to 10TB each, total 20TB)
Quick Access QR Code Remote Viewing on iPhone, iPad, and Android (w/ included Free app)
Smart search for selected area in the video, and smart playback to improve the efficiency.
Supports VGA and HDMI cables.
Remotely Access Using Standard Windows and Mac Browser.
GW Security cameras gives you full management of your belongings wherever you go. Get notified of actual movements directly to your phone when you’re not there . Be informed of any dangers invading your space in real-time.
Receive a photo to your e-mail.
Receive push updates to any mobile device.
10 second video playback alert videos
Downloads & Resources
How to add 41/42 series NVR to GWView
Desktop Software: GW Station
GW4232N2 Manual
| Cameras | 32 Cameras |
|---|---|
| Resolution | 5 Megapixel |
| Camera Style | Dome |
| Color | White |
| Focal-Length | 2.8-12mm Motorized Lens |
| IR Distance | 100ft |
| Lens Type | Motorized |
| Microphone & Speaker | Built-In Microphone |
| Spot Light | No |
| AI Smart Feature | Human Detection |
| Model | GW5076MIP |
| Camera | |
| Image Sensor | 1/3" CMOS |
| Effective Pixels | 5 megapixels |
| Electronic Shutter | AUTO |
| Min. Illumination | 0.01Lux@F1.2(AGC ON), 0Lux IR on |
| Day/Night | Auto/Color/(B/W)/Timing |
| WDR | Digital WDR |
| White Balance | Auto/Manual |
| BLC | Support |
| DNR | 2D/3D DNR |
| Other | Multi-lines OSD, Motion Detection, Privacy Mask, Mirror |
| Encode | |
| Video Standard | H.264/H.265 |
| Video Resolution | Main Stream: 25fps@5MP(2592x1944)/4MP(2592x1520)/3MP, 30fps@1080P/720P Sub stream: 25fps@D1/VGA/360P/CIF, etc. |
| Video Bitrates | 32Kbps - 8Mbps, VBR/CBR |
| Audio Standard | G.711-u/G.711-a/AAC |
| OSD Overlay | Title and Time overlay |
| Smart Event | Human Detection Motion Detection |
| IR Led | |
| IR Led | 24 pcs SMD IR Led |
| IR Distance | 20-30 M |
| Lens | |
| Focal length | 2.8 -12 mm AF lens |
| Zoom | Moto 4x optical zoom |
| Optional Function | |
| POE, audio | |
| Network Services | |
| Protocol | HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP, etc. |
| P2P Cloud | Yes |
| Web | IE , Firefox 32bit ESR |
| Media | CMS, Android, IOS |
| ONVIF | 17.06 compatible |
| General | |
| Network Port | 1-RJ45, 100Mbps, POE optional |
| Power | 12VDC |
| Power Consumption | < 8 W |
| Operating Temp. | -30℃-(+60)℃, 10%-90%RH |
| Model | GW4232N2 | |
| Video/Audio Input | ||
| IP Video Input | 32-ch | |
| Two-way Audio Input | 1-ch, RCA | |
| Network | ||
| Incoming bandwidth | 160Mbps | |
| Outgoing bandwidth | 64Mbps | |
| Local Users | 128 | |
| Protocols | P2P, UPnP, NTP, DHCP, PPPoE | |
| Video/Audio Output | ||
| HDMI/VGA Output | HDMI: 4K (3840x2160)@30, 1920x1080p@60, 1920x1080p@50, 1600x1200@60, 1280x1024@60, 1280x720@60, 1024x768@60 VGA: 1920x1080p@60, 1920x1080p@50, 1280x1024@60, 1280x720@60, 1024x768@60 |
|
| Audio Output | 1-ch, RCA | |
| Recording Resolution | 8MP/5MP/4MP/3MP/1080p/960p/720p/960H/D1/2CIF/CIF | |
| Synchronous Playback | 32-ch | |
| Corridor Mode Screen | 3/4/5/7/9/10/12/16/32 | |
| Decoding | ||
| Decoding format | Ultra265/H.265/H.264 | |
| Live view/ Playback | 8MP/5MP/4MP/3MP/1080p/960p/960H/720p/D1/2CIF/CIF | |
| Capability | 2 x 4K@30, 3 x 5MP@30, 4 x 4MP@30, 5 x 3MP@30, 8 x 1080p@30, 16 x 720p@30,32 x D1 | |
| Hard Disk | ||
| SATA | 2 SATA interfaces | |
| Capacity | up to 10TB for each disk | |
| External Interface | ||
| Network Interface | 2 RJ-45 10M/100M/1000M self-adaptive Ethernet Interfaces | |
| USB Interface | Rear panel：1 x USB2.0, 1 x USB3.0 Front panel：1 x USB2.0 | |
| General | ||
| Power Supply | 12V DC Power Consumption: ≤ 15W( without HDD ) | |
| Working Environment | -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing) | |
| Dimensions(W×D×H) | 380mm × 315mm ×49mm (15.0" × 12.4" ×1.9" ) | |
| Weight ( without HDD ) | ≤ 2.48 Kg (5.47 lb ) | |
