$2,399.00
The newest generation of security camera systems is here. With Commercial 4K resolution, this surveillance system from GW Security will bring a brand new level of detail to your security monitoring. This system includes our GW5516NPN 4K Network Video Recorder with built-in POE switch to avoid extra equipment. Whether you are looking to monitor your business or protect your home, this powerful security camera system will help you secure the things that matter most.
GW5516NPN-GW8539DFIP Specifications
4K NVR can support up to 16 cameras
12 × 8MP Bullet IP Camera
Maximum night vision range
Expandable up to 24TB
GWCamView App
4K video has 400% more pixels in a frame than standard 1080P (2MP) HD. Additional pixels make the digital zoom more effective, providing more details at close distances or the ability to digitally zoom in on details at a greater distance than before.
Enhance the effectiveness of your surveillance system by improving visibility, providing accurate color reproduction, and deterring potential intruders.
Deterrence Effect:
The red/blue alarm lights can be used to deter potential intruders or vandals. The presence of a security camera with visible lights can make criminals think twice before attempting to break in or damage property. Additionally, if an intrusion does occur, the flashing lights can alert nearby residents or law enforcement of the incident.
Improved Color Accuracy:
The color night vision mode provides more accurate color reproduction than traditional night vision cameras, allowing you to see important details like clothing colors or the color of a vehicle. This can be particularly helpful in identifying suspects or providing evidence in legal proceedings.
Enhanced Nighttime Visibility:
With night vision, the security camera can capture clear footage even in low-light or no-light conditions. This is especially useful for outdoor surveillance, where darkness can make it difficult to identify potential intruders or monitor suspicious activity.
Greatly reduce the number of false motion alarms with AI Cameras. AI cameras not only detect motion, the camera alerts when motion is created by a person or a vehicle. Get quick, relevant and accurate data delivered right to your smartphone via push notifications.
Traditional motion detection often creates vast amounts of false alarms in outdoor settings such as trees shaking, vegetation moving with the wind, and other small animals. Our new AI technology is relevant motion detection, seeing only vehicles and human activity. Sending only notifications that matter most.
With Power over Ethernet (PoE), you only need to connect your Ethernet cable to power your PoE security cameras. Data also travels both ways through an Ethernet cable, PoE software not only sends data and commands to devices, but it also collects data. This gives you flexibility to install your security cameras almost anywhere you want, without the extra worries of keeping them plugged in nearby electrical outlets.
Audio recordings can be a good addition to improve your security situation where video recordings cannot provide. A built-in microphone is an extra feature of the GW8539DFIP, allowing synced video and audio recordings in real time. Best used in your home or business.
Please note that there are may be privacy laws in your area that do not allow or limit audio surveillance. Double check with your local authorities before installing your cameras and utilizing any audio recording functions.
GW’s high-quality LEDs allow these HD IP cameras to see up to 85ft in complete darkness for 24-hour-a-day protection. GW Cameras use the latest high intensity IR LED technologies for maximum coverage. The image shown is an actual capture from a 4K camera in total darkness.
IR range and image quality can be affected by surfaces that absorb or reflect the IR light differently when in total darkness. Camera location or position may need to be adjusted to optimize the images. Some ambient lighting provides the best results for night surveillance.
An IP66-rated security camera has a rugged design and durable construction that’s rated for general outdoor use. An IP66-rated camera offers excellent performance even in harsh conditions such as: Dust storms, Wind, rain, sleet, even blowing snow. What performance specs can you count on from an IP66 standardized rating? You can count on an IP66 to provide the following:
Level 6 Dust Protection: The highest level of dust protection, with no intrusion of dust whatsoever permitted.
Level 6 Water Protection: The third-highest level of water protection, impervious to precipitation or hose-directed water streams, blowing snow and sleet.
up to 4K/8MP/8MP/3MP 1536p @ 30fps Realtime each channel
NVR built-in 16 PoE ports and 2 USB ports, 2 SATA HDD port(up to 12TB each, total 24TB)
Quick Access QR Code Remote Viewing on iPhone, iPad, and Android (w/ included Free app)
Smart search for selected area in the video, and smart playback to improve the efficiency.
Support 1-ch HDMI, 1-ch VGA,HDMI at up 4K(3840×2160) resolution.
Remotely Access Using Standard Windows and Mac Browsers.
GW Security cameras gives you full management of your belongings wherever you go. Get notified of actual movements directly to your phone when you aren’t there. Be informed of any dangers invading your space in real-time.
Receive a photo to your e-mail.
Receive push updates to any mobile device.
10 second video playback alert videos
Downloads & Resources
How to add GW55NVR to GWCamView/RXCamView
Desktop Software: VMS Client
GW5516NPN Manual
$38.50
| Cameras | 12 Cameras |
|---|---|
| Resolution | 8 Megapixel |
| Camera Style | Bullet |
| Color | White |
| Focal-Length | 2.8mm Fixed Lens |
| IR Distance | 80ft |
| Lens Type | Fixed |
| Microphone & Speaker | Two-way Audio |
| Spot Light | No |
| AI Smart Feature | Vehicle Detection / Human Detection, Face Recognition |
| Video | |
| Imaging Device | 1/2.7" |
| Effective Pixels | 8MPÂ 3840(H)* 2160(V) |
| Scanning System | Progressive CMOS |
| Min. Illumination | Color 0.007lux @ F1.0(AGC ON) ;Â Â B/W 0 lux @ IR ON |
| Lens Type | |
| Focal Length (Zoom Ratio) | 2.8 mm |
| Max. Aperture Ratio | F No. 1.0 |
| Angular Field of View | Horizontal:110° , Vertical:58°, Diagonal: 133° |
| Min. Object Distance | 2m |
| Lens Type | Fixed(M12) |
| Operational | |
| IR LED | 1 |
| WarmLight | 2 |
| Red Blue Light | 2（1 Red&1 Blue） |
| IR Viewable Length | Up to 25m |
| WarmLight Viewable Length | Up to 20m |
| Type of complementary light | Default warm light, switchable infrared light |
| Motion Detection | Off/On (8 Level) |
| Wide Dynamic Range | DWDR |
| Digital Noise Reduction | 3D DNR |
| Image Setting | Full Color Mode/Day&Night Mode/Schedule |
| White Balance | Auto/Manual |
| Electronic Shutter Speed | 1/5 ~ 1/20000s |
| On-Board Storage | Micro SD slot, up to 256GB |
| Alarm | NA |
| Audio | Built-in microphone&Speaker |
| Hardware Reset | YES |
| Smart Feature | SMD（Human&Vehicle Detection（PD&VD）/Perimeter Intrusion Detection（PID）/ Line Crossing Detection（LCD） |
| Network | |
| Ethernet | RJ45(10/100BASE-T) |
| Video Compression Format | H.265/H.264 |
| Resolution | Mainstream@15fps 8MP （3840* 2160） Substeam@15fps 1080P(1920x1080) |
| Video Quality Ajustment | 512Kbps ~ 6Mbps |
| Bitrate control method | CBR/VBR |
| IP | IPv4 |
| Protocol | TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP,NTP,HTTPS |
| Security | IP address filter;complicated password;Authenticated username and password |
| Application Programming Interface | ONVIF |
| Web Viewer | IE10,11 |
| Environmental | |
| Operating Conditions | -35～+60°C/less than ≤ 95% RH |
| Ingress Protection | IP66 |
| Electrical | |
| Input Voltage / Current | D12V/POE(IEEE802.3af) |
| Power Consumption | TBD |
| Mechanical | |
| Material | Metal&Plastics |
| Dimensions (HxWxD) | 152.3*70.1mm |
| Weight | 282g |
| Model Name | GW5516NPN | ||
| Video | Resolution |
|
|
| Recording Bandwidth | Inputs | 112M | |
| out | 96M | ||
| Performance | |||
| Installation wizard | Yes | ||
| Live/Playback | Compression | Audio: G.711a Video : H.264/H.265 | |
| Frame rate | 4K:45fps 4MP:90fps 2MP:180fps | ||
| AI | yes | ||
| Event | MD(Sensitivity Level 1~8) | ||
| Videlo loss | |||
| Beep, Email, Push notification to Mobile APP | |||
| Playback function | Fast forward / backward (2x, 4x, 8x,16x) | ||
| Slow forward (1/2x, 1/4x, 1/8x,1/16x) | |||
| Playback | Max 16CH playback | ||
| UI/Monitoring | Local | UI5.0 | |
| WEB | IE10/11 Safari V12.1 above Firefox V.52 above Google chrome V.57 above Edge V.79 above | ||
| Mobile viewer | Rxcamview | ||
| Push N/Atification | TUTK/RS | ||
| Interface | |||
| P/W Reset | Factory Reset : Press 10 seconds | ||
| Monitors | VGA | 1（1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 ） | |
| HDMI | 1（1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 , 2560*1440, 3840*2160/EDID） | ||
| Connections | POE | 16POE | |
| Ethernet | 1 RJ45 100/1000 Base-T | ||
| USB | USB2.0*1(front) USB2.0*1+(rear) | ||
| Audio out | 1 | ||
| E-sata | no | ||
| HDD | 2 SATA HDD, each HDD up to 12TBÂ Â (Design reserved 2HDD or 1HDD+1ESATA) | ||
| Line in | 1 | ||
| RS485 | no | ||
| Alarm Input/out | no | ||
| General | |||
| OSD Language | More | ||
| Mechanical design | Dimension (WxDxH) | 300X302X54mm | |
| Electrical | Input Voltage/Current | DC48V/3.75A | |
| Power consumption (excluding hard disk) | 8W | ||
| Environmental | Operating Temperature/Humidity | Temperature : 0°C~+40°C (32°F ~ 104°F) Humidity : Less than 90%RH | |
